Membrane Production

MODIFIED BITUMEN
MEMBRANE PRODUCTION SYSTEM

    WITH MAT REINFORCEMENT

Reichel & Drews’ Modified Bitumen Membrane Production System is a bitumen waterproofing membrane production solution for manufacturing waterproofing membranes that are designed with reinforcements such as fiberglass or woven polyester.

CONFIGURATIONS

Configured to accommodate your unique needs

PRODUCTION

Dual-compound capabilities

INTEGRATED

Mechanical system and electrical controls are fully integrated and precise

EFFICIENCY

Highly-efficient way to produce membrane with carriers

PRECISION

Coater is capable of accurate and consistent compound thickness

SPEED

Production speeds up to 1,000 ft. (305 m) per minute

LOOKING FOR CARRIERLESS PRODUCTION EQUIPMENT?

1
The Carrier Unwind is used to unwind polyester or fiberglass material efficiently.
BUILT IN TENSION CONTROL
SELF LOADING
Unwind Section
2
The Splicing Table is used to bring two pieces of polyester or fiberglass together to allow for gluing or stitching.
PLC CONTROLLED
HOT MELT TAPE & GLUE
Splice Table - Modified Bitumen
3
Dry Mat Accumulators are designed to accumulate the polyester material to support the continuous production run while the material is changed at the splice table.
SERVO DRIVEN
INTEGRATED WEB GUIDE
Dry Mat Accumulator

WANT TO LEARN MORE?

Learn more about our Modified Bitumen Membrane Production Equipment
4
Our coaters consist of electrically heated rolls for safer operation and better temperature control and a Precision Servo Driven Calendar and Scraper Adjustment provide greater coating accuracy, consistency, and safer operation.
REMOTE OPERATOR INTERFACE
ELECTRICALLY HEATED ROLLS
Dual Compound Coater
5
The Surfacing Section will add sand or similar materials to the back of the asphalt coated web.
INDIVIDUAL SERVO MOTORS
QUICK DISCONNECT AVAILABLE
Surfacing Section - Modified Bitumen
6
The Cooling Section allows for the temperature of the web to reduce to the proper cutting temperature.
ACTUATED ROLL SCRAPERS
DUST MANAGEMENT
Cooling Section
7
The Nested Finished Product Accumulator gathers free loops of finished material to help provide a continuous cutting at a desired speed and/or accumulate material if downstream equipment is not running.
Nested Accumulator

WANT TO LEARN MORE?

Learn more about our Modified Bitumen Membrane Production Equipment
8
Our Driven Shock Roll is synced to the winder for consistent and fully integrated tension into the winder. It provides full-roll accumulation for smooth finished goods extraction from the accumulator without stress or jerking action.
Servo Shock Roll - Modified Bitumen
9
The numerous models of Winders address every possible scenario to wind your rolls fast to your predetermined length and with a clean cut.
Winder - Modified Bitumen
10
The Core Inserter is designed to insert a core into a wound roll of modified membrane material as it is ejected off the winder material.
Core Inserter
11
Wound rolls accumulate to a magazine in preparation for the rolls to be up-ended. Combining this with a pallet management system will make this process of palletizing rolls one of your most efficient processes.
Image coming soon
